Olympic Straight Load Floats
Olympic Straight Load Floats
100% Australian made all Olympic Floats come standard with; galvanised chassis & framework, hard wood floors, fully enclosed with barn doors, new light truck tyres and LED lights. Topping the Australian market for over 50 years and highly regarded for their durability Olympic floats offer excellent value for money. Straight load floats are available in a range of different sizes to suit all horses and rider requirements. For horse’s 17hh+, larger models can be modified with extra height and length.
Olympic Straight Load Models:
- Windsor 2 Wheel Brake
- Windsor 4 Wheel Brake
- Royal
- Eldorado
- Grand Prix
from $18,990 Inc GST (plus freight and on road costs)
Model Specifications
| Model | Price | Tare Weight | Gross Weight | Internal Length | Internal Width | Internal Height | Overall Width |
|---|---|---|---|---|---|---|---|
| Windsor 2 Wheel Brake | $18,990 | 990kg | 2000kg | 3.2m | 1.64m | 2.21m | 2.16m |
| Windsor 4 Wheel Brake | $20,990 | 1050kg | 2500kg | 3.2m | 1.64m | 2.21m | 2.16m |
| Royal 4 Wheel Brake | $27,490 | 1060kg | 2900kg | 3.5m | 1.64m | 2.21m | 2.16m |
| Eldorado | $29,690 | 1300kg | 2950kg | 3.7m | 1.64m | 2.21m | 2.16m |
| Grand Prix | $32,490 | 1400kg | 2950kg | 4.05m | 1.64m | 2.21m | 2.48m |
Note: Prices, weights and dimensions may change without notice; weights and dimensions are approximate.
Standard Features
| Model | Electric Brakes | Access Doors | Sliding Side Windows | Front Tack Box | Front Rug Rack | Head Dividers | Swing Out Saddle Rack | Fully Enclosed | Internal Tack Box Door | External Food Bin Holders |
|---|---|---|---|---|---|---|---|---|---|---|
| Windsor 2 Wheel Brake | 2W | 1 | ● | ● | ● | |||||
| Windsor 4 Wheel Brake | 4W | 1 | ● | ● | ● | |||||
| Royal 4 Wheel Brake | 4W | 2 | ● | ● | ● | ● | ||||
| Eldorado | 4W | 2 | ● | ● | ● | ● | ||||
| Grand Prix | 4W | 2 | ● | ● | ● | ● |
Some Optional Extras Include
- Breech bolt
- Additional stone guarding
- Recessed door tie ups
- Water tank
- 240V power
- Extra access door (Regal, Windsor)
- Front rug rack
- Kitchenettes POA (not available in Regal & Windsor)
- Yards
- LED lighting
- Custom paint
- Feed bin holders
